Versa Spreaders
The field-proven, ‘V’-bottom spreader is designed with an all-welded chassis frame. The heavy-duty main-drive system is unparalleled in the industry with a dual hydraulic planetary and 50,000 pound tinsel chain. Dual-plate spinners power a 50 foot even spread pattern for accurate metered distribution. The Versa Spreader handles all types of materials from heavy and light to coarse and fine with a holding capacity of 40 cubic yards. By design, the Versa Spreader has good traction from beginning to end of load
Spreader Dimensions & Specifications
- Width (outside): 98 in (2489 mm)
- Width (inside bottom): 48 in (1220 mm)
- Length: 34 ft (10.4 m)
- Height: 127 in (3226 mm)
- Weight: approximately 17,000 lbs
- Holding capacity: 40 cu yds (31 cu m)
Spreader Hydraulics and Electrical
- Hydraulic wet kit (Optional): up to 55 GPM (210 LPM) at engine RPM includes PTO, pump, controls, & reservoir
- Pressure setting: 2800 PSI (193 BAR )Electrical: 9-way trailer plug
- Road lights: compliant with regulation
Spreader Chassis
- Suspension: air-ride or spring
- Wheels & tires: customer choice
- Wheel brakes: “S” cam 7.5 in x 16 in air released
Spreader Power Train
- Main drive: dual hydraulic motor & planetary
- Drive shaft: 4 in diameter splined
- Main chain: WR-124, 50,000 lb, ultimate strength
- Slat: .63 in x 3 in flat bar
- Spinners: dual 22 in diameter with replaceable abrasion resistant wear plates
Versa Spreader Special Features
- Optional automatic tarp for roof cover
- Up to 50 foot (15.2 m) spread pattern
- Good traction to end of load by design
- Spinner shut-off for end of field turns & road side unloading
- Adjustable, metering rear door for accurate even distribution per acre
- Main chain tensioners: spring, adjustable
- All electric controls in cab
TESTIMONIAL
The Versa Spreader is a very versatile piece of equipment and has changed our company dramatically. We run 12 trailers every day, 10 hours a day, six days a week. We stockpile and spread manure, compost, and sand with it. The farmers we work for love the way they spread because of the pattern they make. What’s great about it is how easily you can change the amount of tons you spread (from six to forty ton rate) with a small adjustment on the back gate.
– Donny King, DK Enterprises, Goodyear Arizona
